TSXPSY3610M
ماژول منبع تغذیه، 24 ولت DC، <= 2700 میلی آمپر، IP20 مدل TSXPSY3610M
power supply module - 24 V DC - <= 2700 mA - IP20
×
![]()
مشخصات کامل
Range of product
Modicon Premium Automation platform
Range of product
Product or component type
Power supply module
Product or component type
Primary voltage
24 V DC 19.2...30 V
Primary voltage
Input current
<= 2700 mA 24 V
Input current
Inrush current
150 A 24 V
Inrush current
I²t on activation
20 A².s
I²t on activation
It on activation
0.5 A.s
It on activation
Protection type
Overload protection secondary circuit
Overvoltage protection secondary circuit
Short-circuit protection secondary circuit
Overvoltage protection secondary circuit
Short-circuit protection secondary circuit
Protection type
Total useful secondary power
50 W
Total useful secondary power
Secondary power
19 W 24 V DC
35 W 5 V DC
35 W 5 V DC
Secondary power
Current at secondary voltage
0.6 A 24 V DC relay power supply
7 A 5 V DC
7 A 5 V DC
Current at secondary voltage
Marking
CE
Marking
Local signalling
1 LED (green) for presence of voltages (OK)
1 LED (red) for battery fault (BAT)
1 LED (red) for battery fault (BAT)
Local signalling
Module format
Double
Module format
Net weight
0.78 kg
Net weight
Immunity to microbreaks
1 ms
Immunity to microbreaks
Dielectric strength
2000 V primary/earth
2000 V primary/secondary
2000 V primary/secondary
Dielectric strength
Standards
UL 508
CSA C22.2 No 213 Class I Division 2 Group C
CSA C22.2 No 213 Class I Division 2 Group A
CSA C22.2 No 213 Class I Division 2 Group D
92/31/EEC
CSA C22.2 No 213 Class I Division 2 Group B
73/23/EEC
89/336/EEC
IEC 61131-2
CSA C22.2 No 142
93/68/EEC
CSA C22.2 No 213 Class I Division 2 Group C
CSA C22.2 No 213 Class I Division 2 Group A
CSA C22.2 No 213 Class I Division 2 Group D
92/31/EEC
CSA C22.2 No 213 Class I Division 2 Group B
73/23/EEC
89/336/EEC
IEC 61131-2
CSA C22.2 No 142
93/68/EEC
Standards
Product certifications
DNV
LR
RINA
GL
ABS
RMRS
BV
LR
RINA
GL
ABS
RMRS
BV
Product certifications
Ambient air temperature for operation
0…60 °C
Ambient air temperature for operation
Ambient air temperature for storage
-25…70 °C
Ambient air temperature for storage
Relative humidity
10…95 % without condensation for operation
5…95 % without condensation for storage
5…95 % without condensation for storage
Relative humidity
Operating altitude
0...2000 m
Operating altitude
Protective treatment
TC
Protective treatment
IP degree of protection
IP20
IP degree of protection
pollution degree
2
pollution degree
Unit Type of Package 1
PCE
Unit Type of Package 1
Number of Units in Package 1
1
Number of Units in Package 1
Package 1 Height
9.5 cm
Package 1 Height
Package 1 Width
18.0 cm
Package 1 Width
Package 1 Length
26.0 cm
Package 1 Length
Package 1 Weight
927.0 g
Package 1 Weight
Warranty
18 months
Warranty
